Dynamode VS-4010 Ficha de datos descargar pdf

VS-4010

4 Port Video Splitter, 150MHz, Metal Case, with cables

INTRODUCTION

APPLICATION

The Multi-Monitor Splitter is compatible with 95% of the monitors on the market and

enables up to 64 monitors to share the information of a host computer simultaneously.

All that is needed to operate the systems is a personal computer (with VGA card), cables,

a power adapter and the Monitor Splitter.

High quality multimedia, Presentation, Video Conference.

Public broadcasting system, Education, Training.

Demo, Stock market, Bank, Security.

Dynamode

SPECIFICATION

Description

1 PC to 4 monitors

PC side

HD-15F x 1

Console side

HD-15M x 4

Max. Resolution

1600 ?1200

Video bandwidth

150MHz

Horizontal Frequency

30-100KHz

Vertical Frequency

43-120Hz

Transmission distance

- Computer to VS-4010: 7.5 M

- Monitor to VS-4010: 75 M

Case Design

Desk top (Metal case)

Dimension

145mm x 102mm x 40mm

Power

DC 9V
